This Sachtler aktiv™ 100 mm fluid head for payloads of up to 12 kg (26.5 lbs.), with unique SpeedLevel™ technology, can be levelled in seconds giving you time to get the perfect shot in documentary, corporate or news applications. The SpeedSwap™ system delivers the fastest way to switch between tripod and slider in seconds giving you ultimate flexibility.
Product Highlights
- Level and lock your head in an instant without missing a second of action
Unique SpeedLevel technology. - Visible from any height or angle - day or night.
Innovative PrismBubble. - Capture extreme low angle shots right down to the ground.
Innovative streamlined mounting system. - Switch between tripod and slider in seconds.
Revolutionary SpeedSwap system. - Create moving stories, whatever the weather.
Performance tested to the extreme.
Technical Specifications
Range | aktiv aktiv |
Payload | 0 kg to 12 kg 0 lb to 26.5 lb |
Counterbalance | 15 + 0 steps 15 + 0 steps |
Drag | 7 + 0 drag settings 7 + 0 drag settings |
Weight | 3 kg 6.6 lb |
Pan Bar Length | 0 mm to 43 cm 0 in to 16.93 in |
Pan Bar Type | Pan bar DV 75 Pan bar DV 75 |
Pan Bar Attachment | 16/-/28 mm 16/-/28 mm |
Pan Bar Count | 1 1 |
Level Bubble | Yes, illuminated Yes, illuminated |
Battery Type | CR2032 CR2032 |
Bowl Size | 100 mm 100 mm |
Camera Plate | Touch & Go plate S Touch & Go plate S |
Temperature Range | -40 °C to 60 °C -40 °F to 140 °F |
Tilt Range | +90° to -70° +90° to -70° |
Sliding Range | 60 mm 2.36 in |
Data Sheets
In The Box
- aktiv™10T fluid head with one pan bar DV and Touch & Go plate S
- Pan bar DV 75 (0992SP)
- Touch & Go plate S (0364)
- aktiv bowl connector 100 mm V2 (S2080-0013)
Compatibility Overview
aktiv10T is compatible with all Sachtler 100 mm tripods (except HotPod)
