Ace M is exclusively available as a package with a 75 mm tripod and a useful transport bag. Anybody who works on uneven ground and “on location” would have an advantage with the two-stage extension tripods featuring a mid-level spreader.

Using a smaller camera doesn’t mean you have to compromise on performance. Whether you are shooting documentaries, weddings or corporate videos with your HDSLR or smaller camera, the Sachtler Ace M Fluid Head gives you broadcast-quality performance. The patented SA-drag™ system and a payload of up to 4 kg means that you get the best pan and tilt performance. The weight compensation comes from proven step switching, making this fluid head perfect for both beginners and professionals looking for a quick and easy bit of kit for smaller projects.

The Ace M Fluid Head weighs just 1.6 kg, with its glass fibre-reinforced composite material that has a non-slip surface feel. This means you can work quickly and intuitively with the confidence that your pans and tilts will always be smooth. The five-step counterbalance makes it simple to balance quickly on almost any surface. High-performance and reliability meet simplicity with the Sachtler Ace M Fluid Head.

Technical Specifications

Range Ace Ace
Payload 0 kg to 4 kg 0 lb to 8.8 lb
Counterbalance 5 counterbalance steps + 0 5 counterbalance steps + 0
Drag 3 horizontal and vertical grades of drag, +0 3 horizontal and vertical grades of drag, +0
Weight 4.4 kg 9.7 lb
Bowl Size 75 mm 75 mm
Spreader Type Mid-level spreader Mid-level spreader
Material Aluminium Aluminium
Tripod Stages 2 2
Pan Bar Count 1 1
Sliding Range 10.4 cm 4.1 in
Tilt Range 90° to -75° 90° to -75°
Temperature Range -30 °C to 60 °C -22 °F to 140 °F
Interface Compatibility Slide-in Slide-in
Transport Length 85 cm 33.5 in
Height Range With Spreader 78 cm to 169 cm 30.7 in to 66.5 in

Data Sheets

In The Box

  • Fluid Head – Ace M fluid head
  • Tripod – Ace 75/2 D with footpads with retractable spikes and mid-level spreader
  • Ace M bag
